Edge Series Laser System – XC2

Light Industrial Desktop CO2XC 2

The Edge XC2 is a 50W galvo CO2 laser for fast engraving on wood, leather, acrylic, paper, fabric, rubber, bone and softer plastics. Because a galvo moves the beam with mirrors instead of a gantry, it engraves much faster than a flatbed CO2, which makes it a good fit for patches, tumblers, promo items and short production runs.

Each system comes equipped with LightBurn software and a full supply kit.

Description

Each system comes equipped with LightBurn software and a full supply kit.

Edge XC2 50W Galvo CO2 Laser
Get a Quote

SPECS

LASER TYPE / POWER
GALVO CO2 / 50W
REPEATED ACCURACY
0.002"
VOLTAGE
110V / 50HZ
MACHINE DIMENSIONS
23" × 21" × 26"
CLASS
4
SPEED
8,000MM / SEC
SUPPORTED IMAGE FORMATS
PLT, BMP, DXF, JPG, TIF, AI, PNG, JPG, ETC.
CRATE DIMENSIONS
32" × 21" × 32"
COOLING METHOD
FORCED AIR
LASER WAVELENGTH
10640NM
BEAM QUALITY
<1.2M2
NET WEIGHT
100 LBS
WARRANTY
2 YEAR
WORKING TEMPERATURE
50–104°F

MATERIALS

Engraving
Cutting
Acrylic
Wood
Leather
Rubber
Paper
Plastics
Fabric
Mdf
Cardboard
Corian
Foam
Fiber Glass
Gold
Aluminum
Silver
Steel
Brass

Additional information

Power

50-Watt
